Conforming To IS:1161:1998 & BS:1139 Equivalent to BS:1775/64
FEATURES:
- Ease and speed in erection and dismantling.
- Rigidity and stability during erection.
- Ease in storing and maintenance
- Eco Friendly
| N.B & SERIES | OUTSIDE DIAMETER (MM) | THICKNESS (MM) | BLACK TUBES WEIGHT (KG/M) | GALVANISED TUBES WEIGHT (KG/M) |
|---|---|---|---|---|
| 15L | 21.3 | 2.0 | 0.951 | 1.01 |
| M | 2.6 | 1.19 | 1.26 | |
| H | 3.2 | 1.42 | 1.51 | |
| 20L | 26.9 | 2.3 | 1.39 | 1.43 |
| M | 2.6 | 1.56 | 1.65 | |
| H | 3.2 | 1.87 | 1.92 | 25L | 33.7 | 2.6 | 1.99 | 2.03 |
| M | 3.2 | 2.41 | 2.46 | |
| H | 4.0 | 2.93 | 2.98 | |
| 32L | 42.4 | 2.6 | 2.55 | 2.62 |
| M | 3.2 | 3.10 | 3.18 | |
| H | 4.0 | 3.79 | 3.87 | |
| 40L | 48.3 | 2.9 | 3.24 | 3.34 |
| M | 3.2 | 3.56 | 3.67 | |
| H | 4.0 | 4.37 | 4.48 | |
| 50L | 60.3 | 2.9 | 4.08 | 4.32 |
| M | 3.6 | 5.03 | 5.33 | |
| H | 4.5 | 6.19 | 6.56 |
